MXN MEMS 光開關

Features

Proven MEMS durability and reliability
Compact Form Factor
TTL UART interface
Qualified to Telcordia GR-1073-CORE and RoHS

Applications

Optical path selection
AsAutomatic optical distribution rack

現在查詢

類別

熱門產品

產品詳細信息

M x N MEMS Optical Switch OXC

M x N MEMS Optical switch is used in optical cross-connect, OXC application. It’s also called Matric Optical Switch. It allows channel selections between M input fibers and N output fibers.

FIBERWDM’s MEMS Modular Single-Mode OXC is based on industry proven, long-life, reliable MEMS 1xN optical switch components. Each MxN OXC consists of M 1xn OSW and N 1xm OSW.

Product Configurations

Note: M*N requires less than 1024.

Optical Specifications

PARAMETER		VALUE	UNIT	NOTE
Wavelength		1290~1330 1525~1568 1600-1650	nm	Or customer specify
Test Wavelength		1310/1550/1625 or 1650	nm
MxN		8x8/8x16/16x16/16x32		M*N≤1024
Insertion Loss	4x4	≤1.4 @S	dB	@CWL,23°C Without Connectors @S: 13 or 15 or 16 @D: 13&15 or 15&16 (if with connectors or support @D, IL increased by 0.4dB)
	4x8	≤1.6 @S
	8x8	≤1.8 @S
	8x16	≤1.9 @S
	12x12	≤2.0 @S
	16x16	≤2.0 @S
	16x32	≤2.3 @S
	24x24	≤2.5 @S
Return Loss		≥45	dB	Or customer specify
Repeatability		≤0.1	dB
Crosstalk		≥50	dB	Or customer specify
Polarization Dependence Loss		≤0.4	dB
Wavelength Dependence Loss		≤0.6	dB	@CWL±20nm, 23°C
Temperature Dependence Loss		≤0.8	dB
Switch Time		≤15 @16x16 ≤25 @24x24	ms	A set of configuration link Eg: M1-N12
Durability		≥1x10⁹	cycle
Maximum optical Power		≤500	mW

Electrical and Mechanical Specifications

PARAMETER	VALUE	UNIT	NOTE
Switch Mode	Non-latching
Control Voltage	12	V	Module
Dimension	150×150×20 @8x8 200x180x18 @16x16 200x180x18 @8x24 312x180x30 @24x24	mm	Module

Environmental conditions

PARAMETER	VALUE	UNIT	NOTE
Operation Temperature	-5~65	°C
Storage Temperature	-40~85	°C
Operation Humidity	5~95	%RH
Storage Humidity	5~95	%RH

Pigtail and connector type/length

PARAMETER	VALUE	UNIT	NOTE
Fiber Type	G657A2 or G657B3 250um bare fiber
Fiber Pigtail(All Ports)	250um fiber or 900um loose tube
Fiber Length(All Ports)	1.00±0.05	m	Or customer specify
Optical Connector(All port)	None		Or customer specify

MECHANICAL DRAWINGS

8x8 OXC MEMS Optical Swtich

16x16 OXC MEMS Optical Swtich

24x 24 OXC MEMS Optical Swtich

相關的標簽 :

想知道這個產品嗎？

發送信息

留言

如果您對我們的產品感興趣并想了解更多詳細信息，請?jiān)诖颂幜粞?，我們將盡快答復您。

主題 : MXN MEMS 光開關
您的電話
您的郵箱 *
寫你的問題 :

相關產品

MEMS VOA 可調衰減器

Product Features Low insertion loss Low polarization dependent Compact size Available in both normally open and normally closed states Excellent reliability Product Application Power Management Receiver protective Channel Balance Instrumentation

1XN MEMS 光開關

Features Proven MEMS durability and reliability Compact Form Factor Fast switching time Qualified to Telcordia GR-1073-CORE and RoHS Applications Opticalsignal switching androuting Optical network protection and restoration Optical path monitoring (Workingwith OTDR or OCM) Instrumentation resource sharing

工業軌式8路 RS-232/RS-422/RS-485 串口服務器

可以用于許多嵌入式網絡控制應用產品：工業自動化生產 安防門禁：網絡門禁、報警設備、紅外探測報警、遠程讀卡器智能家居設備：智能家居網關、智能插座、智能開關 網絡IO控制器：工業遠程IO輸入、遠程繼電器控制建筑智能和能源監控醫療監控設備

應用性能管理-APM

通過監控應用系統的性能、用戶感知，在出現性能問題前，提前發出告警通知；在應用出現異常故障時，幫助用戶快速的定位和解決故障，完善應用監控和分析

400G網絡分光器 400G SR8 MPO16/APC 1分2多模 OM4 50:50網絡流量復制 1U機箱

無源設計：無需供電，節省能源與維護成本。高容量分光：支持 8 條 400G SR8 MPO-16 鏈路，16 個 OTAP 端口，實現雙芯雙向流量復制。流量無損復制：分光比 50:50，100% 鏡像主鏈路流量，不影響主路性能。低損耗高性能：插損≤4.8dB，均勻性≤0.8dB，回波損耗≥55dB，確保信號穩定傳輸。寬溫適應性：工作溫度 - 40℃~+85℃，適合惡劣環境。緊湊機架式：1U 機箱（440×230×44mm），節省機柜空間。多模 OM4 支持：適配 850nm 波長，滿足高速短距傳輸需求。應用場景：用于交換機、防火墻、服務器等設備間的數據采集與分析，解決端口鏡像資源占用問題。

1x8 600um光纖 900 ～1700nm 工業級機械式光開關器件 SMA905接頭

產品應用光傳輸系統中的多路光纖監控組成光纖及各種光器件的測試系統 多光源/探測器自動換接系統 光傳感多點動態監控系統 光測試系統中用于光纖、器件、野外光纜測試實驗室光器件測試研究組建光纖自愈網絡 功能特點 產品具備低損耗、高可靠性內部器件均選用進口元件，可靠性更好模塊化設計，可靈活嵌入各領域系統 控制方式簡單方便易控制內部電路設計故障自檢告知功能

2光8電POE千兆工業級交換機 FW308GPS-2F
